The Benjamin Trail NP Pistol

Monday, May 6, 2013
The Benjamin Trail NP pistol with the cocking assist handle detached.

The Benjamin Trail NP pistol with the cocking assist handle detached.

I have a weakness for air pistols. They are both fun and challenging to shoot. (Heck, any pistol is challenging to shoot because they don’t have the additional support of a shoulder stock.) I particularly enjoy shooting spring-piston air pistols because they deliver a mild jolt to the hand when they go off, and managing the recoil is the key challenge.

Nearly 18 months ago, I became aware that Crosman Corporation had plans in the works to build a spring-piston break-barrel air pistol based on the Nitro Piston powerplant. I was particularly interested because, to the best of my knowledge, no other company is building a break-barrel pistol based on gas ram/gas spring/Nitro Piston technology. From time to time I would send an email to my contact at Crosman and inquire when the pistol would be available. For quite a while, the answer always came back: “Not yet.” A couple of months ago, though, I got an email telling me that Crosman would send me one soon.  And sure enough, not long afterward, a UPS truck arrived bearing a large box containing the Benjamin Trail NP Pistol.

I yanked it out of the box, grabbed some Crosman Premier Light (CPL) 7.9 grain pellets and began banging away at some soup cans at seven yards. I found almost immediately that the NP pistol would punch through one side of a soup can at seven yards, but not both.  I tried the very light non-lead Crosman SSP Pointed pellets that were in the package, but I still could not penetrate both sides of the soup can. The other thing that I found immediately was that this pistol was fun to shoot. My initial impression was: “I like it! Decent rear sight, manageable recoil, useful cocking assist handle, and enough power to defend the birdfeeder at close range, fun to shoot.”

The rear sight hangs slightly over the rear of the receiver.

The rear sight hangs slightly over the rear of the receiver.

Before I tell you about the rest of my experience, let’s take a guided tour of this pistol. The Benjamin Trail NP Pistol is a single-shot, break-barrel pistol in .177 caliber. It stretches 16 inches from end to end, 19 inches with the cocking assist sleeve attached, and weighs just shy of three-and-one-half pounds. A metal notch-type rear green fiber optic sight that is adjustable for windage and elevation hangs over the back end of the receiver. Below that, the powerplant is made of metal and the “stock” (including the pistol grip) is made of a matte black polymer.

The pistol grip is studded with small protrusions that aid in gripping the pistol, and the same black polymer forms a guard around a black polymer trigger. Above the trigger is a push-button safety that displays a red ring when the safety is off. Beyond the trigger guard is a slot underneath the pistol that provides clearance for the cocking linkage.

The Benjamin Tral NP pistol with the cocking assist sleeve attached.

The Benjamin Tral NP pistol with the cocking assist sleeve attached.

Beyond that is a black metal barrel with has a polymer fitting on the end that serves as a protection for the muzzle and a mount for a blade-type red fiber optic front sight. Moving rearward, you’ll find the breech block and the receiver, which has dovetails for mounting the rear sight or a pistol scope or red dot. That’s all there is to the Benjamin Trail NP Pistol.

To ready the pistol for shooting, you could grab the muzzle end of the barrel and pull it down and back until it latches. But the barrel is short and the front sight would dig into the palm of your hand, so Crosman has provided a cocking assist handle that clips over the muzzle fitting but provides a slot for the front sight to poke through. Unlike other pistols that have offered cocking assist devices, the cocking assist handle for the Trail NP is designed to clip to the barrel of the gun so that it stays on while you are shooting it. It extends the length of the pistol by three inches and provides a place to grip the pistol for cocking that won’t dig into your hand.

The sight picture showing the two green dots of the rear sight on either side of the out-of-focus fiber optic red front sight.

The sight picture showing the two green dots of the rear sight on either side of the out-of-focus fiber optic red front sight.

So you grab the cocking assist handle in one hand and the pistol grip in the other and pull the muzzle down and back until it latches. This takes, I estimate, around 30 pounds of effort, but is very smooth and free of any noise. Next, slide a .177 pellet into the breech and return the barrel to its original position. Take aim, push the safety off, and squeeze the trigger.

Now, here’s where things get a little weird. When I first shot the Trail NP pistol, I was banging away at cans using a two-handed weaver grip and pulling straight through the trigger. If you had asked me then, I would have estimated the trigger pull at about five pounds. Later, however, I checked the trigger pull with my Lyman digital trigger gauge and found that the first stage requires 3 lbs. 13 oz, and the second stage is 7 lbs. 13 oz. I was astonished because the trigger didn’t feel that heavy to me. But I rechecked the pull a couple of times and those really are the numbers.  The second stage also has a lot of creep. When I was shooting groups, I found I would pull halfway through the second stage, recheck the sight alignment, and then pull the rest of the way to trigger the shot.

The Benjamin Trail NP sends 7.9 grain Crosman Premier pellets down range at 506 fps average, which works out to 4.49 foot-pounds of energy. Crosman claims, on the package, 625 fps with lead-free pellets, but that turned out to be too low.  The Benjamin Trail NP pistol sent 4-grain Crosman SSP Pointed pellets through my chronograph at a sizzling 720 fps, generating 4.6 foot-pounds of energy at the muzzle. The report was pretty subdued, not dead quiet but not loud enough, it seemed to me, to disturb the neighbors.

Shooting two-handed from a sitting position in my SteadyAim harness at ten yards, I found that the Trail NP would deliver 1.5-inch five-shot groups with just about any pellet I fed it. Generally I could put 3 shots into a group you could cover with a quarter but then I would get a couple of outliers that would expand the group.

In addition, as I was completing this review, I heard from the editor of Airgun Hobbyist magazine. He said that he had bought the Benjamin Trail NP pistol and could not get it to sight-in at 10 yards. There simply wasn’t enough elevation adjustment, he said. I did not have that problem with the sample that Crosman sent me, but I had to adjust the sight almost to the very limit of its travel. In addition, I have seen similar online comments from a couple of shooters. At this point, I do not know if the sight adjustment problem with this pistol is limited to a handful of units or is more widespread. Certainly this is something that Crosman should look into, in my opinion.

So where does that leave us with the Benjamin Trail NP pistol? Despite the heavy trigger, I found it a lot of fun to shoot. It is an excellent choice for an afternoon of plinking and is accurate enough and has sufficient power to defend the birdfeeder at close range. It would also be an appropriate pistol for controlling pigeons or rats in a barn. I believe a lot of airgunners will enjoy shooting this pistol as it stands so long as the sight can be properly adjusted, but with less trigger weight and creep, a pistol that I found enjoyable would be significantly improved.

Til next time, aim true and shoot straight.

-          Jock Elliott

Tags: , , , , ,
Posted in Airguns | 5 Comments »

Going Rogue – Part II

Monday, September 3, 2012

The Rogue pushes into your shoulder and wants to lift the muzzle when the shot is triggered. I recommend shooting off a bipod.

To get the Benjamin Rogue ready for shooting, you first have to install batteries to power the electronics that control this air rifle. Lay the Rogue on its left side and remove the right side cover screws with a .0625 allen wrench. Install two AA batteries (the folks at Crosman recommend lithium batteries for long life) and replace the cover. Remove the cover on the foster fitting at the end of the air reservoir and charge the Rogue to 3,000 psi with a SCUBA tank or high pressure pump. The display on the left side of the receiver will tell you how much pressure is in the air tube.

The Rogue magazine holds six .357 caliber bullets.

Load the Rogue clip with six .357 bullets and slide it into the breech from the left-hand side until it clicks. Slide the bolt forward and down. This will push a bullet from the magazine into the barrel. Now, note this: the Rogue is designed with an extra position on the bolt. It has to be moved back about a quarter of an inch into the READY TO FIRE position before the electronic action can fire. To allow hunters to be able to walk around with the Rogue charged and loaded, there is a bolt activation lever just below the bolt that, when in the DISABLED position, prevents the bolt from inadvertently moving back into the READY TO FIRE position. The bolt activation lever enables and disables the bolt, and the push-button safety near the trigger enables and disables the trigger.

So, to fire the Rogue, flip the bolt activation lever to ACTIVE, pull the bolt back to READY TO FIRE, push the safety off, take the slack out of the first stage of the trigger, and squeeze the second stage.

A 145 grain Nosler Benjamin eXTREME Bullet next to a 7.9 grain Crosman Premier Pellet.

What happens next is really quite astonishing – the Rogue kicks. Ed Schultz says it has roughly the recoil of a 28-gauge automatic shotgun. (I’ve never shot a 28-gauge shotgun, but I’ll take his word for it.) The recoil is not punishing by any means, it doesn’t slam into your shoulder, but the Rogue definitely pushes back against you, and the muzzle tries to lift. When I first shot the Rogue at Crosman, I was using cushions for a rest, and it didn’t work very well. In fact, given the weight of the Rogue, and its propensity to recoil and lift, I consider that a bipod, which can be readily attached to the Picatinny rail under the forearm, is an essential accessory for this air rifle. A bipod makes the Rogue much easier to shoot well.

The report of the Rogue is about as loud as a subsonic .22 rimfire, but – thanks to the shrouded barrel – not nearly as loud as it might be. (The loudest precharged air rifle I ever shot was a Sumatra .22, which I thought sounded like a 12-gauge shotgun. I hated it.) The Rogue, considering the power it generates, is very modest in the sound it makes, but still it is not the air rifle for shooting in a suburban backyard . . . unless, of course, you have an urgent need to kill a coyote (even then, BE SURE to check with local authorities to make sure that shooting an airgun is legal where you are.).

I put six 145-grain Nosler bullets through the chronograph. Here are the velocities in order (fps): 783.2, 754.6, 750.9, 749.0, 741.3, and 739.1. (After six shots — a magazine-load — the air pressure drops to about 2,000 psi and the reservoir needs to be refilled.) That works out to 752.18 fps average and – drumroll please – 182.2 foot-pounds of energy at the muzzle. That is one pot-load of power, roughly 50% more than a .22 rimfire. That’s about 10 times the power of most air rifles sold in the United States, power enough for hunting coyotes and hogs. That’s also enough power that you want to be extremely careful in choosing your backstop for target shooting with the Rogue.

Five shots at 50 yards with the Rogue.

Shooting the Rogue off its bipod at 50 yards, I put five Nosler bullets into a group that measured 1.4 inches from edge to edge.  A number of bullets are available for the Rogue, including a 95 gr. hollow point, a 170 gr. flat nose, a 159 gr. round nose, and a 127 gr. flat nose.

The power with which it hits is impressive. I’m told that when Crosman brought out the Rogue at the Northeast Regional Field Target Championship in 2011, they put a target on a cinderblock at 50 yards, and the Rogue punched a hole in the cinderblock.

Bottom line: I think a lot of hunters and pest control professionals will find the Rogue an interesting and useful tool.

Til next time, aim true and shoot straight.

-          Jock Elliott

Tags: , , ,
Posted in Airguns | 6 Comments »

Going Rogue – Part I

Monday, August 27, 2012

The Benjamin Rogue is a big, powerful .357 caliber precharged pneumatic air rifle.

When I’m not writing this blog for www.airgunsofarizona.com, I occasionally have other writing assignments in the airgun field. For the past several years, for example, I have written the “airguns update” for the SHOT Show Daily newspaper that is handed out each day at the SHOT Show.

Now, there is too much going on at the SHOT Show to print each day’s edition of the newspaper fresh from scratch. That would be the road to madness. As a result, a considerable chunk of the SHOT Show Daily is pre-printed well ahead of the show. The article that I write about what’s new in the field of airguns is part of that preprinted material.

So here’s what happens: sometime in August (usually) my editor at the SHOT Show Daily will contact me and given me a deadline for my airgun article. The deadline is typically sometime in October. So I begin contacting all the airgun manufacturers and distributors who will be exhibiting at the SHOT Show and I tell them that I need the pertinent information about whatever new products they will be exhibiting at the SHOT Show by a date that is usually a week before the day I have to turn in my story to my editor.

As a result, I usually know about a lot – but not all – of the cool new airgun stuff that will be unveiled at the SHOT Show. I have to keep all of this information is strictest confidence until it is officially released at the show. I have also learned over the years that many of the new products that are announced at SHOT Show will not be commercially available until later – sometimes much later – in the year.

So I was talking with one of the nice marketing people at Crosman about some products that were announced at the SHOT Show 2012 when she asked, “Have you ever seen a Benjamin Rogue?” I had to admit that I had not and didn’t think anything more about it until three weeks later one arrived at my door.

Until the Rogue showed up, the largest bore airgun I had ever shot was a .25 caliber.  Quarterbore, as it is sometimes called, is a nice fat caliber that serves very well for hunting small game, varminting, and pest control, but the pellets might weigh, say, 19 to 25 grains. The Rogue, though, is a .357 caliber precharged pneumatic air rifles that launches “bullets” that might weigh as much as 170 grains.  You don’t have to be Einstein to figure out that if the Rogue could launch these pellets faster than I could throw them, it would be fairly easy to generate energy at the muzzle that would be in excess of a .22 rimfire cartridge. That’s a lot of power for an airgun. I didn’t think that the pellet trap I ordinarily use would be capable of stopping pellets from the Rogue.

Further, I figured any airgun capable of generating that kind of power was likely to be pretty loud. So immediately I had a problem: I needed to find a place where I could shoot the Rogue safely and where it wouldn’t disturb neighbors.  I mentioned this to the folks at Crosman, and one of them suggested I bring the Rogue with me when I covered the Northeast Regional Field Target Championship. I did, and the first time that I got to shoot the Rogue was in the company of Ed Schultz, who is the head honcho for engineering at Crosman.

This display and these three buttons serve as the control center for the Rogue.

The Benjamin Rogue is a big, hairy-chested, powerful precharged pneumatic air rifle. It weighs 9.5 pounds before you mount a scope or bipod, stretches four feet long, and is a six-shot repeater. At the extreme aft end of the Rogue is an AR15 style buttstock that can be expanded or collapsed after squeezing a release lever.  Forward of that is the receiver, which has a liquid crystal display on one side and three buttons for making various control selections. The Rogue is electronically controlled, including a digital pressure display and an electronic valve that precisely meters the amount of air that is used for each shot. The shooter can choose from two power settings and various bullet weights to custom-tailor the performance of the Rogue to their preference.

Crosman has recently simplified the software that controls the Rogue. “We realized the no one wants to shoot a big bore airgun on low power,” Schultz says, “so we eliminated that option.”

Below the left side of the receiver is an AR-style pistol grip and forward of that is the trigger and trigger guard, above which is a push-button safety. Ahead of the trigger guard, you’ll find the forestock, part of which is covered with a tan polymer guard that is textured for gripping. Beyond that, the rest of the forestock is black and has a Picatinny rail for attaching accessories.

Moving forward again, the air tube, finished in tan, has a screw-off cap at the end. Undo it, and there is a male foster fitting for filling the air reservoir. Above the air tube is the barrel, which is shrouded and has baffles to quiet the report. Moving rearward along the barrel, the receiver has a 3/8 inch dovetail for mounting a scope. In the middle of the receiver is the breech which has a slot large enough for accepting a 6-shot rotary magazine.

On the right side of the panel, you’ll find a removable panel, the bolt, and a small bolt activation lever. That’s it.

Next time, we’ll take a look at what’s it is like to shoot the Rogue.

Til then, aim true and shoot straight.

-          Jock Elliott

Tags: , , ,
Posted in Airguns | 4 Comments »

And a good time was had by all . . .

Monday, July 16, 2012

On July 6, 7, and 8, I spent three days in Bloomfield, NY, at the Crosman facilities attending the Northeast Regional Field Target Championship, and I thought I share some of my thoughts, photos, and impressions of the experience. (If you simply want to see the results, you can check them out here: http://www.crosman.com/croswords/?p=2704 )

The shooter’s meeting under the large tent.

To start, the match was incredibly well run and organized. It was as if Crosman were conducting a clinic on how to host a field target match. Red shirts, worn by Crosman folks, were in evidence everywhere, helping out, making sure things went well. And they did. The Regional Field Target Match was scheduled to start at 9 am Saturday morning, and by 8:50 am, everything was in place and ready to go.

By the time I arrived shortly after noon on Friday, a number of shooters were already on the sight-in range. It was very warm and humid, and the Crosman folks had large coolers filled with ice and bottled water available next to the sight-in range and also under a large tent where shooters could escape from the sun. By the end of the day on Friday, there was a 55-gallon drum filled with empty water bottles.

The two field target courses were about 1/3 of a mile apart. Many shooters drove from one to another, but Crosman also had an ATV and trailer for transportation between the two courses.

Almost every type of field target rig imaginable was in evidence, from Remington Nitro-Piston break barrel rifles being shot off shooting sticks to multi-kilobuck full race match rifles.

Hans Apelles’ rig featured a very tall scope mount.

Hans Apelles was shooting in Hunter Division with a very tall scope mount. When I asked about it, he pointed to his son, Ray. Ray explained, “Dad’s shooting in Hunter. Scopes are limited to 12x. That makes it hard to range-find beyond 35 yards. With this setup, everything from 33 to 55 yards is basically the same mil-dot.”

Here’s what Hans’ mil-dot chart looked like.

When I spoke to Kevin Yee, who had flown in from California to shoot in the Open Division, Piston Class, he complained that he wasn’t doing so well, but he posted a 50 out of a possible 60 on both days and beat the highest score in Open PCP.

Kevin Yee has, easily, the world’s funkiest sidewheel scope knob. It’s built that was so he can adjust it with his trigger hand while shooting offhand.



Larry Bowne shot the entire match offhand.

The match on Saturday was interrupted by a spectacular but short-lived storm.

Dan Finney shot prone most of the time in Hunter PCP.

Ray Apelles designed the championship courses with 1.5 inch killzones throughout, but no one cleaned the course.

In the middle of the WFTF shoot-off for first place, Greg Sauve grins for the camera while Ray Apelles focuses on a shot.

The pistol match featured almost every imaginable style of pistol shooter.

The B course (lanes 16-30) was cooler under the trees, but all shooters agreed that it was harder to dope the wind there.

Hector Medina (white hat with neck cloth) won Hunter Piston by nearly 20 points. That’s Art Deuel shooting an HW98 in the foreground.

Richard Bassett (tan hat) is congratulated by Hans Apelles for winning the Quigley Bucket Challenge. Over 40 shooters took a crack at the 1.75 inch bucket at 55 yards with non-glass sights.

Dan Brown not only took third in WFTF and won Hunter Pistol, but gets the “Nice Guy of the Year” award for providing much needed navigational help to Your Humble Blogger.

In all it was a wonderful match!

Til next time, aim true and shoot straight.

- Jock Elliott

Tags: , , , , ,
Posted in Airguns | 9 Comments »

Defending the Garden – Part III

Monday, April 2, 2012

My first job was to check out the guns for 10-meter accuracy. While all of them come equipped with iron sights, I decided to test them with optional scope or peep sight mounted. As you might expect from telescopic sights that cost less than $30, neither the Crosman nor the Daisy scope would make any of your shooting friends insanely envious, but at the same time, if what you are looking for is a sighting device that is adequate to the task of removing vermin from the garden at relatively short range, these scopes are up to the job.

When it got down to the actual evaluation, I decided to test the air rifles at two pumping strokes less than the maximum the factory allows. Experience has shown that the extra two strokes add only a little to the velocity. Incidentally, despite what you might have heard from other sources, pump up airguns are extremely consistent in their velocity. You can even pump one up, let it sit for half an hour or more, and still get very consistent results.

At eight pumps, the Daisy 22X happily shot 1-inch (edge-to-edge) groups at 10 meters with most pellets, including Daisy MaxSpeed .22 wadcutters and Crosman .22 Premiers. Group size dropped to 3/4 inch with RW Meisterkugeln flat-nosed .22 pellets.

At 8 pumps, the Crosman 2200B was extremely finicky about pellets. It shot huge groups – some over three inches — with every pellet but the RWS Meisterkuglns. With these pellets, groups settled down to 1 1/16th inch, not a great showing, but sufficient to the job. (Crosman tells me that its quality standard for the 2200B is 1 1/2 inch groups at 10 yards, with 1 inch being typical.)

The Benjamin 392, at 6 pumps, was the least pellet-sensitive gun tested, shooting half-inch groups with almost any pellet I fed it.

Then it was time for the can test. Shooting from a sitting position at 20 meters, I shot at steel soup cans with each gun, using Meisterkugln pellets and the same number of pumps as I had used at 10 meters. All three guns easily hit the can in the center mass and punched through one side. The 392 dimpled the backside of the can trying to make an exit hole.

At 15 meters, the Benjamin 392 went in one side and out the other. The Crosman 2200B went in one side and made a large dimple on the back side. The Daisy 22X pierced on side and made a smaller dimple on the back side.

At 10 meters, both the 392 and the 2200B blew through both sides of the can like a hot knife through butter. The Daisy 22X pellet lodged in the exit hole on the backside. Note well: these shots were made with wadcutter pellets. They generally do not penetrate well, but when they do, the typically leave large wound tunnels. Dome-headed pellets certainly would penetrate more efficiently.

It is also important to note that two air rifles of the same model, but two serial numbers apart, can perform better with radically different pellets. So, just because my Crosman 2200B achieved a certain level of performance with Meisterkugln pellets, that doesn’t mean your 2200B will perform similarly with the same pellets. Testing with different pellets is the only way to find out what works in your gun.

The bottom line: The Daisy 22X pumps the easiest, offers moderate accuracy, but penetrated the least on the can test. The Crosman 2200B offers moderate pumping effort, good penetration in the can test, but the lowest accuracy. The Benjamin 392 pumps hardest, hits the hardest, and offers the most accuracy, but costs nearly twice as much as the others. As the man said: “Ya pays yer money, and ya takes yer choice.” Any of these guns could be used for defending garden at 60 feet or less, but my first choice would be the Benjamin 392 if my wallet could stand it.

Til next time, aim true and shoot straight.

-          Jock Elliott

Tags: , , , ,
Posted in Airguns | 5 Comments »

Defending the Garden – Part II

Monday, March 26, 2012

But before I get to my take on the actual air rifles, some words about my selection. I decided to go with American pump-up .22 caliber air rifles for several reasons. The first, quite frankly, is that I have a weak spot for pump-up air guns. I own several, and I enjoy shooting them frequently. In addition, pump-up guns are generally easy to shoot; they don’t jump and buck the way many spring-piston air rifles do. Pump-up rifles are also typically less expensive than their spring-piston counterparts, and they are usually a fraction the cost of pre-charged air rifles which are filled from a SCUBA tank or high pressure pump.

Lastly, I was inspired. Recently I received a copy of an excellent book American Air Rifles by James E. House (Krause Publications). In it, he evaluates more than a dozen American-made air rifles. His words reminded me that you don’t need an expensive European or Asian model to enjoy a great deal of shooting satisfaction – and utility — with an air rifle. Thanks, Mr. House.

One of the first challenges that I faced was generating some sort of performance standard. What kind of performance would be necessary to send Jabba the Chuck to that Big Salad Bar in the Sky? Since I didn’t have three equal National Institute of Standards-certified pest animals lining up to be shot for evaluation purposes, and at that time I did not have a chronograph, I chose the next best thing . . . soup cans. Yup, good oldCampbell’s to the rescue.

My reasoning was thus: a steel soup can is small enough and tough enough that, if you can hit it and cleanly pierce at least one side, you can probably hit and punch through the skull of a varmint. I have killed animals with air guns that wouldn’t pass this test, but I wouldn’t recommend it. If possible, I prefer to drop ‘em where they stand. (I chose .22 caliber for all three guns for the same reason.)

So let’s have a look at our three candidates.

Daisy 22X.

The Daisy 22X is 37.75 inches long and weights 4.5 lbs. It is the lightest of the three guns. It has 20.8 in rifled steel barrel. The manual says it can be pumped up to 10 times and claims 530 fps with 8.6 fp energy but doesn’t specify what weight pellets are involved. The 22X is a handsome gun with a wooden buttstock (with plastic buttplate) and wooden forearm. The receiver is metal.

The 22X is loaded by dropping pellets into the breech on top of the receiver. The bolt is opened by pulling a plastic lever on the right side of the receiver. Opening the bolt also cocks the action. With a scope attached to the rail on top of the receiver, loading requires placing the pellet in the slot on the top of the receiver just to the right of the breech and rolling the pellet into the breech. The 22X is the easiest to pump of the three rifles, but, as we’ll see in a bit, it comes at a price.

In 2002, the suggested retail price of the 22X was $73.95. The Daisy 2-7x scope that I used for testing carried an SRP of $29.95.

Crosman 2200B

The Crosman 2200B measures 39 inches long and weighs 4 lbs. 12 oz., just a few ounces more than the Daisy. The 2200B has a 20.79 inch rifled steel barrel, and the factory manual claims 525-595 fps at 10 pumps with 14.3 gr. pellets. The buttstock and forearm are plastic, and the receiver is metal and is equipped with a scope rail. Overall, the appearance is clean and appealing, and it looks like a “real” rifle. The entire plastic forearm moves to pump up the gun, and the 2200B requires only slightly more pumping effort than the Daisy.

The 2200B loads by dropping pellets into the breech on the right side of the receiver. A plastic lever opens the breech and cocks the action. Loading requires tipping the gun on its side. The slot leading to the breech is somewhat deep, and there is no elegant way to control the descent of a pellet to the breech itself. As a result, sometimes nose-heavy domed pellets arrive at the breech sideways or backwards. Sometimes jiggling the gun or dumping the pellet out and starting over is necessary to set things right.

The suggested retail price of the 2200B was $69.95, and the 4x Crosman scope that was used during testing was $9.95.

Benjamin 392

Benjamin 392, manufactured by Crosman Corporation, is 36.25 inches long and weighs 5.5 lbs, making it both the shortest and the heaviest of our three candidates. The 392 manual states this gun will produce velocities of 685 fps at 8 pumps but does not reveal the weight of the pellets used in making that determination.

It doesn’t take Holmesian powers of observation to figure out the 392 is solidly built. The only plastic used on this air rifle is the buttplate. The buttstock is solid wood, and so is the forearm which also serves as the pumping lever. (The 392 is also the hardest of the three guns to pump.) The breech and bolt are made of metal, but unlike the Daisy and the Crosman, there is no scope rail on top of the receiver. Holes for attaching a Williams peep sight are tapped into the side of the receiver, and that’s what I used for a sighting system.

The 392 can be scoped using intermounts from Crosman for around $15.00 and attach a scope (or a red dot sighting device) forward of the receiver. In the case of a scope, this requires either a long eye relief scope (a la Colonel Jeff Cooper’s scout rifle concept) or putting both scope rings forward of the turrets and letting the body of the scope hang over the receive.

The suggested retail price of the Benjamin 392 was $149.95, and the Williams peep was $27.95, making this combo by far and away the most expensive of the three guns tested.

Next time, we’ll see how these three rifles perform.

Til then, aim true and shoot straight.

-          Jock Elliott

Tags: , , , ,
Posted in Airguns | 3 Comments »

Defending the Garden – Part I

Monday, March 19, 2012

Back in 2002, my wife and I decided that we would like to grow some fresh veggies. The next couple of blogs recall what happened then and make some recommendations in case you need to defend your garden.

There is no way to confirm this with rock-solid certainty, but according to my back-of-the-ammo-box calculations, it was the most expensive salad bar ever. And I had not tasted so much as a single bite of it – not a morsel of wax bean, not a sliver of tomato.

My wife and I had labored hard through sun and rain over the darn thing. We hired the roto-tiller guy (who showed up with a commercial-grade Troy-Bilt tiller and a business card that read “I dig my work.”) to pulverize a section of our lawn. Then we raked, picked rocks (lots of ‘em), ran strings and pegs, and planted: tomatoes, corn, squash, a couple of kinds of beans, peppers. It was a work of art. We were regular Arlo Guthries out there: “inch by inch, row by row, gonna make this garden grow . . .”

Then, by the sweat of our brow, we surrounded it with steel fence posts and sturdy critter-proof wire fencing. And we watched it grow and tended it. Then, just as the tender new plants were seriously establishing themselves, we went away for a weekend.

When we came back . . . someone . . . something . . . had given our garden a crew cut. Where once there had been vibrant plants bursting with the promise nature’s bounty, there was stubble. I was in utter shock: for the amount of money, sweat and effort we had put into this thing, we could have had veggies FEDEXed to us fromChile. Who was the culprit?

Then I saw him. Not one of the deer that wander through the yard. No, this was smaller, more insidious – good old Marmota monax, a woodchuck. And what a woodchuck this was! Round, firm, fully packed, he was so swollen and porcine he could barely wriggle through the hole he had dug under the fence. He was so fat he had a roll behind his neck. I had worked my butt off all spring so this groundhog could enjoy some mitey fine gourmet meals at my expense.

I wanted to shoot him so baaaaad! “Honey, call the supermarket and see if they got any Woodchuck Shake ‘N’ Bake, will ya?” (I never did terminate this particular woodchuck with extreme prejudice. Instead I took my revenge in laughter – he was so obscenely corpulent, likeGarfieldthe cat, his legs barely reached the ground. I referred to him as Jabba the Chuck.)

If you’ve got a problem with a woodchuck, a rabbit, a squirrel or other varmint munching on your garden or prize azaleas, and you live in or near a populated area, there is a problem. The law generally takes a very dim view of popping off any kind of firearm near dwellings, and many jurisdictions have specific prohibitions about shooting guns. Besides, any reader of this blog worth his or her salt will naturally be conscious of the safety of neighbors and their property.

In my case, I live within one-half mile of a major technical university. Shooting any kind of powder is strictly verboten. There is hope, though. Many places have absolutely nothing to say about shooting airguns. Recently, I’ve had my hands on three vintage American .22 caliber pump-up airguns that will dispatch vermin quite well at short ranges.

Next time, we’ll talk about them.

Til then, aim true and shoot straight.

-          Jock Elliott

Tags: , , , ,
Posted in Airguns | 5 Comments »

Benjamin Scout Rifle

Monday, June 27, 2011

I hunt very little, but I do get called from time to time to do pest control “favors” for the neighbors. When that happens, my go-to airgun is usually a Benjamin 392 .22 caliber pump-up rifle.

There’s a lot to like about the humble 392: it’s easy to shoot well; it delivers enough power to terminate whatever you might reasonably want to shoot with an air rifle; the power can be readily varied; it doesn’t cost a ton of money, and it delivers good longevity and value for an air rifle in its price class. Mostly I like the 392 because it is light, easy to handle, and reasonably accurate.

But all is not 100 percent tickety-boo in 392-ville. The factor iron sights – particularly the rear sight – that come with the 392 are lackluster. Williams makes a peep sight especially designed for the Benjamin that works pretty well, with some caveats.

First, the Williams peep has no screw adjustment for windage.  As a result, to adjust windage, you must loosen both screws that prevent side-to-side movement of the peep.  Then you gently move the windage adjustment with your fingers.  At this point there is the very great risk that it will slip completely out of adjustment, forcing you to start from scratch.  Once you gingerly ease the windage into what you think is the proper position, you must then re-tighten the screws without jiggling the sight out of adjustment.  Elevation adjustment, however, is as simple as turning a screw.

Second, once the Williams peep sight is properly mounted on the Benjamin 392 and adjusted, there is the problem that, at various distances, the front sight blade appears to be wider than the thing that you are aiming at. This, of course, can be a problem with any rifle with a blade front sight.

Finally, at dawn or dusk or anytime the light doesn’t lend itself to high contrast, aiming with metallic sights can be challenging.  For all of these reasons, there are times when I yearn for a better sighting system for the 392.

Mounting a scope on a 392 is problematic. There are no dovetails on the receiver. Some tuners will cut dovetails into the receiver, but even if you mount a scope on the receiver, unless it is a very short scope, it raises the question of where do you put your hands while pumping? If you mount a normal-length scope, you are forced to pump with one hand on the 392’s pistol grip or use the scope itself as a handle for pumping.

But there is another alternative for solving the problem. Some years ago, Colonel Jeff Cooper touted the idea of the scout rifle – a rifle of no more than one meter long (39.4 inches), no more than 3 kilograms (6.6 pounds), with a forward-mounted low-power scope. The forward-mounted scope allows the shooter to keep both eyes open, to aim with precision and yet be aware of the surroundings at the same time.

I was intrigued with the idea of the scout rifle, and, using intermounts clamped to the barrel of the 392, I built one with a forward mounted pistol scope.

Here's my first attempt at a scout rifle, with a forward-mounted pistol scope.

I liked it well enough, but recently I wanted a Benjamin scout rifle that offered better performance in low-light conditions. The good folks at Crosman were kind enough to send me the goodies to put such a scout rifle together.

They consist of a Benjamin 392, Benjamin B272 intermounts, 2-piece medium profile dovetail rings for 30mm scopes, and a CenterPoint Multi-TAC Quick Aim Sight, which is basically a green/red-dot sight with four reticles.

Putting it all together first requires clamping the intermounts to the barrel on either side of the rear sight. Next, loosen the weaver rings on the CenterPoint Multi-TAC Quick Aim Sight and slip them off. Slide the 30mm medium profile dovetail rings on where the weaver rings were and tighten them. Finally, attach the dovetail rings to the intermounts on either side of the rear sight.

Here's my newest version of a scout rifle, with a red/green dot sight.

Tah-dah! You’re done. The result is a fast-handling pest control gun that’s a lot of fun to shoot and easy to pump because there is plenty of room to grab the rifle just forward of the breech. I find my head position behind the dot sight is a bit higher than looking through a peep, but not so high that it bothers me. The CenterPoint sight displays either red or green dots (your choice), and a continuously variable rheostat in the sight makes it easy to set the degree of brightness that you like best for the shooting conditions. The sight allows the shooter to select one of four different reticles simply by rotating a knob: a single dot, three vertical dots, a dot with a dash on either side and the bottom, and a dot within a circle.

That knob on the left side of the sight allows the shooter to select among four different reticles. The big knob on top controls the color and the brightness.

In the end, I really like this Benjamin scout rifle. It’s light, easy to handle, and quick to aim and should make a dandy tool for doing those pest control favors for neighbors.

Til next time, aim true and shoot straight.

-          Jock Elliott

Tags: ,
Posted in Airguns | 9 Comments »

Field Target at EFTCC

Monday, May 16, 2011

If you have never tried field target competition, you really owe it to yourself, as an airgun enthusiast, to give it a go. It’s a lot of fun.

On May 1, 2011, I attended and competed in a field target match put on by the Eastern Field Target Competitors Club (EFTCC) at the Dutchess County Pistol Association in Wappingers Falls, NY.

Field target is the fine art of shooting at metallic silhouettes of squirrels, rabbits, birds, and the like. These silhouettes are generally 4-12 inches high. There is a hole, called the kill zone, in the silhouette, and behind the hole is a paddle. If you put a pellet cleanly through the hole, it hits the paddle, and the target falls down. If you hit the face plate of the target or split a pellet on the edge of the kill zone, the target stays upright. What makes field target challenging is that the range to the target can vary from 7 to 55 yards, and the size of the kill zone can range from .25 inches to 1.875 inches. Further – and this is key – there is no correlation between the range to the target and the size of the kill zone. A one-inch kill zone at 10 yards is fairly easy to hit, but a one-inch kill zone at 50 yards can be downright challenging.

Normally, you score one point for each target you knock down (and no points if you fail to drop the target), but the May 1 EFTCC match was scored on a risk/reward system: you got one point if you knocked the target down from a sitting, prone, or kneeling position, but you scored two points if you dropped the target from a standing position.

The catch in all this is that it is harder to shoot from a standing – or offhand – position. Most lanes had two targets, and you could take two shots at each, four shots in all in each lane. If you were successful with all four shots from, say, a sitting position, you would get four points for that lane, but if you were successful with all four shots from a standing position, you would get eight points. So, is it worth the risk to attempt the more difficult by higher scoring standing shots? That was the question facing the competitors.

Six classes were available for competition at EFTCC: Hunter, WFTF (World Field Target Federation), Pistol, PCP, Spring Gun, and Junior. There were entrants in all classes but Pistol.

Below is my attempt to capture the day in pictures.

The day was gorgeous: mid-70s and low wind. It started with signing up for a class to compete in.

The shooting lanes are along the left edge of the photo, the check-in table on the right.

A couple of typical field targets. Hit the yellow kill zone, and the target goes down.

Can you spot the field target on the tree?

Here it is up close.

 You could spot just about any type of air rifle in the competition.

Tom Holland took first in the WFTF class with this Steyr LG110FT.

Michael Arroyo finished second in Hunter with this Beeman R11.

Glenn Thomas campaigned a Gamo CFX.

Hector Medina took second in Spring Gun Division with a Diana 54.

Veronica Ruf competed with an HW95.

Brian Williams goes prone in Hunter class with his .20 caliber Daystate Air Wolf.

In Hunter class, Greg Shirhall reloads his custom-stocked Marauder.

Robert Bidwell shot a QB78PCP in Junior Class.

Paul Bishop won Spring Gun Division with this custom-stocked HW98.

Jerry LaRocca won Hunter class with his .22 caliber Diana 56TH.

Ron Zeman shot an Air Arms S300 in PCP Division.

Art Deuel finished second in the PCP Division with this customized Marauder.

Nathan Thomas sights in a Marauder. He won the PCP Division with it.

Your Humble Correspondent with his trusty FWB150.

Match Director and Team Crosman member Ray Apelles shot a Marauder Hybrid bullpup that was specially built for ease of transportation to the FT World Champsionship in Italy.

Ray's father Hans is co-Match Director and the other half of Team Crosman. Here he is shooting his lefthanded Marauder Hybrid Bullpup.

And a good time was had by all!

The FT match was a lot of fun. You get to meet a lot of nice people, enjoy shooting for half a day, and see some interesting equipment. What’s not to like?

Til next time, aim true and shoot straight.

- Jock Elliott

Tags: , , , , , , ,
Posted in Airguns | 9 Comments »

An answer for Sean’s pest control question

Monday, February 21, 2011

Recently, I received a response to the blog from Sean, who said:

“I need an air rifle to kill some roosting pigeons and feral cats at a commercial property in Tucson. I want to limit the distance of the shot as much as possible in case I miss my shot.

Any suggestions for an appropriate rifle would be helpful.

Thanks,

Sean”

Thanks for the question, Sean. I’ll do my best to provide a useful response.

Your first big concern should be to determine the legality of your situation. Is it legal for you to be discharging an air rifle at this commercial property and is it also legal for you to be killing pigeons and feral cats? The last thing you want is a legal hassle because someone saw you terminating pigeons or feral cats and decided to make an issue of it. That is not the time to discover that you are on the wrong side of the law. So check it out first. If legality is a problem, you might want to see what your options are with a pest control professional.

You mention “I want to limit the distance of the shot as much as possible in case I miss my shot.” Safety is your second big concern. You really have to take a critical look at the area where you intend to shoot. What, indeed, will happen if you miss your shot? Where will your shot go? Will you hit adjoining properties, possibly critical or sensitive equipment, or will your shot go into the air and you have no idea where it will land? (Understand, Sean, that I am not getting on your case here, but simply pointing out that it is your responsibility to be sure of the background where your shot is going to land.)

Study your field of fire and look for alternative shooting positions. If you can arrange a position where you are shooting downward into the ground or into a backstop you devise, that could be very helpful.

One of the unknown variables in the question you pose is the distance at which you will be shooting. That will influence what type of air rifle you choose. You also don’t mention what type of commercial property is involved, and that may make a difference as well.

Scoped HW30.

Some years ago, I did a profile on pest control professional Alan Becker. He is called frequently to kill birds in grocery stores, and one of his concerns is over-penetration. “If he pellet goes through the bird, I have to find it. I don’t want to take the risk that it might be in a food product.” For that reason, Becker uses a Beeman R9 in .177 that launches .177 pellets at 875-900 fps, and a CZ630, also a .177, with a velocity around 600 fps (a readily available equivalent would be the Beeman R7 or HW30). With an HW30 or R7, you should be able to kill pigeons out to about 25 yards.

Here's an older Benjamin 392 set up Scout rifle style with a red dot sight.

If you are forced to shoot upward at roosting pigeons and don’t want to risk damaging the roof, you might consider a Benjamin 392 pump-up rifle. By varying the number of pumps, you can vary the power and velocity of the shot. At as little as 3 pumps, you might be able to kill the pigeon without “killing” the roof.  The 392 can be difficult to scope, but can be outfitted with a peep sight or a pistol scope mounted out on the barrel in “scout rifle” fashion.

The Benjamin Marauder Pistol, outfitted with shoulder stock and scope.

Another good candidate is the Benjamin Marauder pistol/carbine, the power of which can be adjusted, but it’s a bit of a hassle.

The FX Gladiator offers tons of shots, super easy power adjustment, and a high degree of stealth.

Another consideration is noise. Some pest control situations require the utmost in stealth. The .177 Marauder rifle is very, very quiet, and the power can be adjusted, but it isn’t quick and easy. If you want a PCP rifle that offers a lot of shots per fill, power that is adjustable at the flick of a switch, very muted report, and excellent accuracy, the FX Gladiator Tactical is an outstanding choice.

Finally, Sean, whatever you choose, be certain that you practice, practice, practice until your shot placement is precise and sure.

Til next time, aim true and shoot straight.

-          Jock Elliott

Tags: , , , , ,
Posted in Airguns | 12 Comments »

« Older Entries
